8114 front

8114

Ciena’s 8114 is a hardened, modular 2.4 Tb/s aggregation router with 400GbE coherent support. As a 2RU high-end aggregator, it flexibly balances 48 ports of 1/10/25GbE SFP28—all of which support Ethernet, eCPRI, and XGS-PON and are 25GS-PON ready—with 6 x 100GbE QSFP28 fixed ports and two 800 Gb/s field-replaceable unit (FRU) modular ports, with a MACsec option. Each modular port can support Ethernet or coherent modules, including the option of 100, 200, and 400 Gb/s coherent WaveLogic™ 5 Nano (WL5n) on QSFP-DD or CFP2-DCO, serving various use cases.

Features and benefits

  1. Temperature-hardened (-40°C to +65°C) for temperature-challenged or space-constrained locations

  2. 48 x 1/10/25GbE and 6 x 100GbE fixed ports

  3. Two flexible 800 Gb/s slots provide maximum port speeds and capacities at 100G, 200G, and 400G

  4. IP routing, SR-MPLS, Carrier Ethernet, and SRv6 ready

  5. Rich timing and synchronization

  6. Hardware-assisted routing and switching OAM scaled to deliver 100GbE services with guaranteed SLA differentiation

FRU modules

FRU model of the 8114 product

  • 2 x 100G/200G/400G QSFP-DD
  • Grey or coherent
  • MACsec version available

FRU model of the 8114 product

  • 2 x 100G/200G/400G CFP2-DCO
  • Coherent

FRU module of the 8114 product

  • 8 x 40G/100G QSFP28
  • Grey

FRU module of the 8114 product

  • 12 x 10G/25G SFP28
  • Grey
  • MACsec
